TECH INFORMATION

• 350W (EIAJ) total power
• 10" (254mm.) custom coaxial speakers
• 7 input channels mixer, with wide choice of balanced / unbalanced input options
• 16 preset Internal Digital Effects section, including effects combinatio
• Lightweight, interlocking components adopting luggage style transportation system
• Three helpful handles (one for each speaker and one for the main unit) allow easier carriage.
• Ideal compact portable audio system to ENJOY YOUR MUSIC!
• Microphone / Line Input
• Frequency Response: 10Hz to 55KHz ¡+/- 3 dB
• Microphone Input Impedance: 3.9kΩ
• Line Input Impedance: 10kΩ
• Microphone Input S / N ratio: 94dB
• Microphone Inputs: Balanced XLR connectors
• Line Inputs: Balanced / unbalanced, 1/4" (6.3mm.) /  TRS jack connectors
• Tape Inputs: Unbalanced RCA jack
• Inputs Distortion (THD&N): 0.04% at 0dBu, 1KHz
• Channel EQ: High shelving  +/- 15dB @ 12KHz  / Low shelving  +/- 15dB @ 80Hz
• Aux Send: 1 with paths for DSP internal section, external DSP section and Monitor Out
• DSP Section: 24 - bit HALL, ROOM, VOCAL, PLATE, STEREO DELAY, REV ¡Ï DELAY, and REV ¡Ï CHORUS combinations
• Master Section: Master Level knob, 4 LEDs level meter, 7 - band graphic output EQ, and DSP Return level
• Output Master EQ: 7 - band, +/- 15dB @ 63Hz, 160Hz, 400Hz, 1KHz, 2.5KHz, 6.3KHz, 16KHz
• Monitor Section: Master Level knob, 4 LEDs level meter, and 1/4" (6.3mm.) MONITOR OUT jack
